Littelfuse_458規格書
Ampere Rating(A) | Amp Code | Marking | Max Voltage Rating(V) | Interruping Rating | Nominal Cold Resistance(Ohms) | Nominal Melting I2t(A2sec) |
| 1.0 | 001. | 1 | 75V | 50A@75VDC 50A@48VAC | 0.180 | .168 |
1.25 | 1.25 | 1.25 | 0.125 | .313 | ||
1.5 | 01.5 | 1.5 | 0.099 | .548 | ||
1.6 | 01.6 | 1.6 | 0.092 | .562 | ||
2 | 002. | 2 | 0.0695 | .952 | ||
2.5 | 02.5 | 2.5 | 0.06 | 1.408 | ||
3 | 003. | 3 | 0.049 | 2.289 | ||
3.15 | 3.15 | 3.15 | 0.045 | 2.457 | ||
3.5 | 03.5 | 3.5 | 0.0375 | 4.00 | ||
4 | 004. | 4 | 50A@75VDC 50A@32VAC | 0.032 | 4.832 | |
5 | 005. | 5 | 0.027 | 7.938 | ||
6.3 | 06.3 | 6.3 | 0.0192 | 14.37 | ||
7 | 007. | 7 | 63V | 50A@63VDC 50A@32VAC | 0.0175 | 20.48 |
8 | 008. | 8 | 0.0058 | 13.448 | ||
10.0 | 010. | 10 | 0.00465 | 15.0 |
